Operasi Dan Maintenance Bts3900 1.0 1i3q56

Security Level:

Operasi dan Maintenance

BTS3900

www.huawei.com

HUAWEI TECHNOLOGIES CO., LTD. HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential Huawei Confidential

Struktur Sistem Operasi dan Maintenance

Remote Maintenance

U2000 Client

Local Maintenance LMT

BTS3900

HUAWEI TECHNOLOGIES CO., LTD.

U2000 Server

Huawei Confidential

Page2

Konek Local BTS

Default Local OM IP address: 192.168.0.49 Setting PC IP same segment, such as: 192.168.0.88

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page3

Pengenalan BTS LMT • ke LMT

Local OM IP address:192.168.0.49 name: : hwbs@com

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page4

LMT • Komponen LMT Window Utama

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page5

Operasi Base Station(MML Mode) • Operasi MML window

MML Search MML Tree

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page6

Pengenalan MML command • Struktur MML command : Action + Object  Main action: ADD/MOD/RMV/SET/DSP/LST/SWP/BLK/UBL  Main objective: BRD/RRU/CELL/SCTPLNK/IPPATH

• Contoh:  DSP BRD  BLK BRD  UBL BRD

Black: optional

Red: compulsory

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page7

Alarm Classification





Alarm Type



Alarm Severity



Fault alarm



Critical alarm



Event alarm



Major alarm



Minor alarm



Warning alarm

The fault alarm Classification 

Cleared alarm



Active alarm

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page8

Alarm Box • Alarm box melakukan audit dan menampilkan alarm. Merah, orange, kuning, dan hijau merupakan indikator alarm pada alarm box yang mengindentifikasikan critical, major, minor, dan warning alarm secara aktual. Suara alarm punya perbedaan di setiap tingkatannya.

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page9

Monitoring Alarm  Browsing

Alarms

Monitoring Alarms

 Querying

dan modifikasi konfigurasi alarm

HUAWEI TECHNOLOGIES CO., LTD.

 Filter

Huawei Confidential

Fault Alarm

Page10

Browsing Alarm/Event

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page11 Page11

Filtering Fault Alarm/Event

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page12

Query dan Modifikasi konfigurasi alarm

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page13

Mengatur Log Alarm

 Query

log

alarm LST ALMLOG

Managing the Alarm Logs  Setting

Storage Conditions of Alarm Logs SET ALMCAPACITY

HUAWEI TECHNOLOGIES CO., LTD.

 Query

Storage of Alarm

Logs LST ALMCAPACITY

Huawei Confidential

Page14

Query Log Alarm/Event

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page15

Query Kondisi Penyimpanan Log Alarm • LST ALMCAPACITY

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page16

Browsing Current Alarms

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page17

Browsing Current Alarms (Cont.)

Nama alarm di query Pengaturan waktu dari alarm

Tampilan korelasi alarms set dari NE atau U2000.

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page18

Browsing Current Alarms (Cont.)

Filter alarm atau event berdasarkan sumber alarm

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page19

Browsing Current Alarm

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page20

Menampilkan info detail alarm

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page21

Tampilkan Alarm dalam Mode Topology

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page22

Clear Alarm secara manual

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page23

Query Alarm dari Template

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page24

Query Alarm dari Template

HUAWEI TECHNOLOGIES CO., LTD.

Pilih template yang tersimpan di server

Huawei Confidential

Page25

Membuat template query alarm

Klik Add HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page26

Membuat template query alarm

Pilih sesuai kebutuhan

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page27

Membuat template query alarm Pilih site yang akan di query

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page28

Melihat Board Label dari U2000 • Pilih Maintenance > Device , Klik-Kanan board, dan Pilih Query Board Inventory

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page29

Health cek dari U2000 • Pilih Maintenance>Network Health cek > NE Health cek dan Klik Create Task icon

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page30

Health cek Report • Klik-Kanan View Report

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page31

Health cek Report(Cont.)

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page32

VSWR Test di U2000 • Pilih Maintenance > RF Performance Test > VSWR Test dan Pilih NE yang akan di tes

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page33

Deteksi RF Interference • Pilih Maintenance > RF Performance Test > Interference Measurement

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page34

Reset Board GUI mode

MML

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page35

Block/Unblock Board Block board di GUI mode

Unblock board di GUI mode

Block board MML

Unblock board MML: UBL BRD HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page36

query status board • Display Board (DSP BRD) GUI mode

MML

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page37

Query Info Board GUI mode

Board Manufacturing Information Board Version Information Board U/DSP Occupancy

MML

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page38

RRU Operation Chain level 0

Chain level 1

RRU Chain GUI mode on U2000

MML

physical information dari RRU chain

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page39

Display Port RI • Query dynamic information tentang port RI di RF atau BBU

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page40

Query Software Version • Query Main area dan standby area software : LST SOFTWARE

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page41

Query Software Version • LST VER

The Version in main area

The Version of different services

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page42

BTS Software • BTS software dari FTP server ke BTS

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page43

ing the Incremental Configuration File

SFTP server configuration

Transfer Type

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page44

File Device Archive

SFTP server configuration

Transfer Type

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page45

Transfer File Konfigurasi Data

SFTP server configuration

Transfer Type

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page46

Back Up Data Konfigurasi (Based on LMT) • BKP/ULD CFGFILE

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page47

Back Up Data Konfigurasi (Based on U2000) • Manually Backing Up NE Data

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page48

Maintenance Clock • Clock Source Type

• Operation dan Maintenance MML  LST CLKMODE  DSP CLKSTAT  DSP CLKSRC

HUAWEI TECHNOLOGIES CO., LTD.

Clock type

Huawei Confidential

Page49

Query status dari clock

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page50

Monitor Channel Status 2G • monitor channel status

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page51

Modifikasi Status Cell istrative 2G • Block atau unblock local cell

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page52

VSWR Test • Run STR VSWRTEST untuk memulai VSWR test

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page53

Cross Feeder Test • Run STR CROSFEEDTST untuk memulai Cross Feeder Test

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page54

Check Board status

Apabila di board UMPT GUL Berarti ada 3 system yang bekerja 2G,3G,4G

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page55

General Network Topology

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page56

Check Status Port transmisi di BTS LST ETHPORT untuk check status port trans normal atau tidak

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page57

Check Device IP LST DEVIP untuk mengetahui IP yang terkonfigure

Dari 4 IP diatas : 3 IP Service dan 1 IP OAM

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page58

Check OAM IP LST OMCH untuk mengetahui IP OAM

IP OAM yang terconfigure

IP U2000

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page59

Check IP OAM Status Normal

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page60

Check Service IP yang terconfigure Command

Control Mode Manual Mode IP Service 3G

Link Number diatas 1000 IP Service 2G ( Abis )

Service IP

Control Mode Auto Mode IP Service 4G

IP Tujuan HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page61

Check Vlan 4G dan OAM dan GW IP LST VLANMAP untuk mengetahui vlan 4G dan Vlan OAM

GW IP 3G segment IP sama dgn IP service 3G

GW IP OAM, segment IP sama dgn OAM IP

GW IP 2G, segment IP sama dgn IP service 2G GW IP 4G segment IP sama dgn IP service 4G

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page62

Check vlan 2G dan vlan 3G yang terconfigure

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page63

Check 4G IP LST SCTPHOST untuk mengetahui IP Service 4G

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page64

Check Mac addres yang diterima di BTS

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page65

Check software version

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page66

Check cell 2G Normal

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page67

Check cell 3G Status Normal

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page68

Check status cell 4G Normal

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page69

Check status S1 Interface

Command

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page70

Check pengguna 4G yang di handle BTS

HUAWEI TECHNOLOGIES CO., LTD.

Huawei Confidential

Page71

Thank you www.huawei.com
